Precio desde

N/A

Potencia

51.5kW at 8000 r/min

Máximo. Torque

70N·m/6000 r/min

Peso seco (KG)

219

Especificaciones técnicas

  • TYPE

    2-cylinder/4-stroke/8-valve

    Displacement (cc)

    698

    Bore x Stroke (mm)

    ø83×64.5

    Power

    51.5kW at 8000 r/min

    Max torque

    70N·m/6000 r/min

    Compression ratio

    11.6:1

    Fuel system

    EFI

    Valve train

    DOHC

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

    Ignition

    T.C.I.

  • Gearbox

    6-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Frame

    Steel trellis frame

    Front wheel

    Aluminum alloy

    Front suspension travel (mm)

    140

    Front tyre

    120/70 ZR17

    Front brake

    Dual discs

    Front brake diameter (mm)

    320

    Rear wheel

    Aluminum alloy

    Rear suspension

    Mono-shock-absorber

    Rear suspension travel (mm)

    26.5

    Rear tyre

    160/60 ZR17

    Rear brake

    Disc

    Rear brake diameter (mm)

    260

  • Dry weight (kg)

    219

    Seat height (mm)

    810

    Overall length (mm)

    2200

    Overall width (mm)

    925

    Overall height (mm)

    1390

    Ground clearance (mm)

    190

    Wheelbase (mm)

    1505

    Fuel capacity (L)

    20

    Top speed (km/h)

    180

    Max load (kg)

    202

    Battery

    12V11.2Ah
