Prezzo da

$ 68,900

Energia

6.3kW at 7500 r/min

Max. Coppia

9.2N·m/6000 r/min

Peso a secco (KG)

97

Specifiche tecniche

  • TYPE

    1-cylinder/4-stroke/2-valve

    Displacement (cc)

    124

    Bore x Stroke (mm)

    ø53.5×55

    Power

    6.3kW at 7500 r/min

    Max torque

    9.2N·m/6000 r/min

    Compression ratio

    9.0:1

    Fuel system

    EFI

    Valve train

    SOHC

    Starter

    Electric & kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

    Ignition

    T.C.I.

  • Gearbox

    CVT

    Final drive

    V-belt

    Clutch type

    Automatic

  • Frame

    Flat scooter

    Front wheel

    Aluminum alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    82

    Front tyre

    70/90-14

    Front brake

    Disc

    Front brake diameter (mm)

    220

    Rear wheel

    Aluminum alloy

    Rear suspension

    Mono-shock-absorber

    Rear suspension travel (mm)

    55

    Rear tyre

    80/90-14

    Rear brake

    Drum

    Rear brake diameter (mm)

    130

  • Dry weight (kg)

    97

    Seat height (mm)

    750

    Overall length (mm)

    1820

    Overall width (mm)

    700

    Overall height (mm)

    1060

    Ground clearance (mm)

    137

    Wheelbase (mm)

    1280

    Fuel capacity (L)

    4.9

    Top speed (km/h)

    90

    Max load (kg)

    157

    Battery

    12V6Ah
