Preis ab (UVP)

$ 88,800

Leistung

11.3kW at 8500 r/min

Max. Drehmoment

13.5N·m/7000 r/min

Trockengewicht (KG)

126

Technische Daten

  • TYPE

    1-cylinder/4-stroke/4-valve

    Displacement (cc)

    149.8

    Bore x Stroke (mm)

    ø57×58.7

    Power

    11.3kW at 8500 r/min

    Max torque

    13.5N·m/7000 r/min

    Compression ratio

    11.3:1

    Fuel system

    EFI

    Valve train

    SOHC

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

    Ignition

    T.C.I.

  • Gearbox

    6-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Frame

    Backbone

    Front wheel

    Aluminum alloy

    Front suspension travel (mm)

    88

    Front tyre

    70/90-17

    Front brake

    Disc

    Front brake diameter (mm)

    240

    Rear wheel

    Aluminum alloy

    Rear suspension

    Mono-shock-absorber, preload adjustable

    Rear suspension travel (mm)

    27

    Rear tyre

    110/70-17

    Rear brake

    Disc

    Rear brake diameter (mm)

    220

  • Dry weight (kg)

    126

    Seat height (mm)

    787

    Overall length (mm)

    2010

    Overall width (mm)

    675

    Overall height (mm)

    1150

    Ground clearance (mm)

    160

    Wheelbase (mm)

    1325

    Fuel capacity (L)

    4.8

    Top speed (km/h)

    110

    Max load (kg)

    184

    Battery

    12V6Ah
