起始价格

N/A

最大功率

15.5kW at 5500 r/min

最大扭矩

29N·m/4500 r/min

干重 (KG)

197

技术参数

  • TYPE

    1-cylinder/4-stroke/2-valve

    Displacement (cc)

    374

    Bore x Stroke (mm)

    ø72.7×90

    Power

    15.5kW at 5500 r/min

    Max torque

    29N·m/4500 r/min

    Compression ratio

    8.5:1

    Fuel system

    EFI

    Valve train

    SOHC

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

    Ignition

    T.C.I.

    Emissions (CO2)

    71 g/km

    Consumption

    3,1l /100 km

  • Gearbox

    5-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Frame

    Double-cradle

    Front wheel

    Spokes

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    121

    Front tyre

    100/90-19

    Front brake

    Disc

    Front brake diameter (mm)

    300

    Rear wheel

    Spoke

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    55.5

    Rear tyre

    130/80-18

    Rear brake

    Disc

    Rear brake diameter (mm)

    240

  • Dry weight (kg)

    197

    Seat height (mm)

    780

    Overall length (mm)

    2170

    Overall width (mm)

    820

    Overall height (mm)

    1120

    Ground clearance (mm)

    165

    Wheelbase (mm)

    1440

    Fuel capacity (L)

    12

    Top speed (km/h)

    120

    Max load (kg)

    190

    Battery

    12V8Ah
