Precio desde

N/A

Potencia

19kW at 9250 r/min

Máximo. Torque

21.1N·m/8000 r/min

Peso seco (KG)

164

Especificaciones técnicas

  • TYPE

    1-cylinder/4-stroke/4-valve

    Displacement (cc)

    249

    Bore x Stroke (mm)

    ø72×61.2

    Power

    19kW at 9250 r/min

    Max torque

    21.1N·m/8000 r/min

    Compression ratio

    11.2:1

    Fuel system

    EFI

    Valve train

    DOHC

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

    Ignition

    T.C.I.

  • Gearbox

    6-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Frame

    Steel trellis frame

    Front wheel

    Aluminum alloy

    Front suspension travel (mm)

    135

    Front tyre

    110/70 R17

    Front brake

    Disc

    Front brake diameter (mm)

    280

    Rear wheel

    Aluminum alloy

    Rear suspension

    Mono-shock-absorber

    Rear suspension travel (mm)

    60

    Rear tyre

    150/60 R17

    Rear brake

    Disc

    Rear brake diameter (mm)

    240

  • Dry weight (kg)

    164

    Seat height (mm)

    800

    Overall length (mm)

    2070

    Overall width (mm)

    840

    Overall height (mm)

    1300

    Ground clearance (mm)

    170

    Wheelbase (mm)

    1390

    Fuel capacity (L)

    18

    Top speed (km/h)

    129

    Max load (kg)

    190

    Battery

    12V6Ah
