Price From

N/A

Power

35kW at 7000 r/min

Max. Torque

50.3N·m/6500 r/min

Dry Weight (KG)

212

Tech Specs

  • TYPE

    2-cylinder/4-stroke/8-valve

    Displacement (cc)

    754

    Bore x Stroke (mm)

    ø88×62

    Power

    35kW at 7000 r/min

    Max torque

    50.3N·m/6500 r/min

    Compression ratio

    11.5:1

    Fuel system

    EFI

    Valve train

    DOHC

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

    Ignition

    T.C.I.

    Emissions (CO2)

    114 g/km (35 kW: 96 g/km)

    Consumption

    4,9 l/100 km (35 kW: 4,1 l/100 km)

  • Gearbox

    6-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Frame

    Steel trellis frame

    Front wheel

    Aluminum alloy

    Front suspension travel (mm)

    140

    Front tyre

    120/70 ZR17 M/C

    Front brake

    Dual discs

    Front brake diameter (mm)

    320

    Rear wheel

    Aluminum alloy

    Rear suspension

    Mono-shock-absorber

    Rear suspension travel (mm)

    48

    Rear tyre

    180/55 ZR17 M/C

    Rear brake

    Disc

    Rear brake diameter (mm)

    260

  • Dry weight (kg)

    212

    Seat height (mm)

    800

    Overall length (mm)

    2140

    Overall width (mm)

    870

    Overall height (mm)

    1160

    Ground clearance (mm)

    180

    Wheelbase (mm)

    1460

    Fuel capacity (L)

    15

    Top speed (km/h)

    145

    Max load (kg)

    195

    Battery

    12V11Ah
